Max. Static Load4300 Kg
BrakeDC 110V, 1.0 A
Weight300 Kg
| Model | Load [In kg] |
Speed [In m/sec] |
Ratio | Sheave [In mm] |
Rope [In mm] [PITCH 19/15M.M.] |
Ropping | Power [ KW ] |
Power [ HP ] |
Pole | Travel / Height [ Mtrs. ] |
|---|---|---|---|---|---|---|---|---|---|---|
| HE - 140 | 408 | 0.65 | 40/1 | 530 | 3X13 / 4X10 | 1 : 1 | 4.5 | 6 | 6P | 50 |
| HE - 140 | 408 | 0.75 | 40/1 | 410 | 4X10 | 1 : 1 | 4.5 | 6 | 4P | 50 |
| HE - 140 | 408 | 1.00 | 40/1 | 530 | 4X13 | 1 : 1 | 5.6 | 7.5 | 4P | 50 |
| HE - 140 | 408 | 1.50 | 50/2 | 530 | 4X13 | 1 : 1 | 6.75 | 9 | 4P | 50 |
| HE - 140 | 544 | 0.65 | 40/1 | 530 | 3X13 / 4X10 | 1 : 1 | 5.6 | 7.5 | 6P | 40 |
| HE - 140 | 544 | 0.75 | 40/1 | 410 | 4X10 | 1 : 1 | 5.6 | 7.5 | 4P | 40 |
| HE - 140 | 544 | 1.00 | 40/1 | 530 | 4X13 / 4X10 | 1 : 1 | 6.75 | 9 | 4P | 40 |
| HE - 140 | 544 | 1.00 | 50/2 | 610 | 3X13 / 4X10 | 2 : 1 | 5.6 | 7.5 | 4P | 40 |
| HE - 140 | 1000 | 0.32 | 40/1 | 530 | 4X13 | 2 : 1 | 5.6 | 7.5 | 6P | 30 |
| HE - 140 | 1000 | 0.5 | 40/1 | 530 | 4X13 | 2 : 1 | 6.75 | 9 | 4P | 30 |
| HE - 140 | 1000 | 0.65 | 50/2 | 410 | 5X10 | 2 : 1 | 7.5 | 10 | 4P | 30 |
