Max. Static Load2050 Kg
BrakeDC 110V, 0.81 A
Brake TypeDisc
Pole20
RatingIP 41
Weight120 Kg
| Type | Load [In kg] |
Car Speed [In m/sec] |
Sheave [In mm] |
Rope [In mm] [Pitch 12mm] |
Volts | Power [ KW ] |
Rated Current [ A ] |
Rated Tourque [ Nm.] |
Frequency [ Hz ] |
Speed [ RPM ] |
Travel Height [ RPM ] |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HGL-400H-4P-050 | 272 | 0.5 | 200 | 4 x 8Ø | 220 | 0.7 | 5.5 | 70 | 15.92 | 95.0 | 12 |
| HGL-400H-4P-050 | 272 | 0.5 | 200 | 4 x 8Ø | 380 | 0.7 | 3.5 | 70 | 15.92 | 95.0 | 12 |
