Max. Static Load5200 Kg
BrakeDC 110V, 1.0A
Weight350 Kg
| Model | Load [In kg] |
Speed [In m/sec] |
Ratio | Sheave [In mm] |
Rope [In mm] [PITCH 19/15M.M.] |
Ropping | Power [ KW ] |
Power [ HP ] |
Pole | Travel / Height [ Mtrs. ] |
|---|---|---|---|---|---|---|---|---|---|---|
| HE - 165 | 544 | 0.65 | 50/2 | 410 | 4 X 10 | 2:1 | 5.6 | 7.5 | 4P | 60 |
| HE – 165 | 544 | 0.75 | 40/1 | 410 | 5 X 10 | 1:1 | 7.5 | 10 | 4P | 60 |
| HE – 165 | 544 | 1.50 | 50/2 | 530 | 4 X 13 | 1:1 | 9 | 12 | 4P | 60 |
| HE – 165 | 680 | 0.65 | 50/2 | 410 | 4 X 10 | 2:1 | 5.6 | 7.5 | 4P | 40 |
| HE – 165 | 680 | 0.75 | 40/1 | 410 | 5 X 10 | 1:1 | 7.5 | 10 | 4P | 40 |
| HE – 165 | 680 | 1.00 | 40/1 | 530 | 4 X 13 | 1:1 | 9 | 12 | 4P | 30 |
| HE – 165 | 884 | 0.65 | 40/1 | 530 | 4 X 13 | 1:1 | 9 | 12 | 6P | 26 |
| HE – 165 | 884 | 1.00 | 50/2 | 610 | 3 X 13 / 4 X 10 | 2:1 | 9 | 12 | 4P | 30 |
| HE – 165 | 1000 | 0.75 | 50/2 | 530 | 4 X 13 | 2:1 | 9 | 12 | 4P | 30 |
| HE – 165 | 1360 | 0.65 | 50/2 | 410 | 5 X 10 | 2:1 | 9 | 12 | 4P | 30 |
| HE – 165 | 1500 | 0.50 | 40/1 | 530 | 4 X 13 | 2:1 | 7.5 | 10 | 4P | 30 |
| HE – 165 | 2000 | 0.30 | 40/1 | 530 | 4 X 13 | 2:1 | 9 | 12 | 6P | 20 |
