Max. Static Load800 Kg
BrakeDC 110V, 1.0 A
Weight 130 Kg
| Model | Load [In kg] |
Speed [In m/sec] |
Ratio | Sheave [In mm] |
Rope [In mm] [PITCH 12M.M.] |
Ropping | Power [ KW ] |
Power [ HP ] |
Pole | Travel / Height [ Mtrs. ] |
|---|---|---|---|---|---|---|---|---|---|---|
| HE - 3.5 | 150 | 0.32 | 50/1 | 305 | 2/3 X 8 | 1 : 1 | 1.5 | 2 | 6 P | 15 |
| HE - 3.5 | 250 | 0.32 | 50/1 | 305 | 2/3 X 8 | 1 : 1 | 2.2 | 3 | 6 P | 10 |
| HE - 3.5 | 250 | 0.45 | 50/1 | 305 | 3 X 8 | 1 : 1 | 2.2 | 3 | 4 P | 10 |
| HE - 3.5 | 272 | 0.38 | 30/1 | 305 | 3 X 8 | 2 : 1 | 2.2 | 3 | 4 P | 15 |
