Max. Static Load2300 Kg
BrakeDC 110V, 2.0 A
Brake TypeDrum
Pole20
Volts380 V
Weight250 Kg
| Type | Load [In kg] |
Car Speed [In m/sec] |
Sheave [In mm] |
Rope [In mm] [Pitch 12mm] |
Power [ KW ] |
Rated Current [ A ] |
Rated Tourque [ Nm.] |
Frequency [ Hz ] |
Speed [ RPM ] |
Travel Height [ Mtrs ] |
|---|---|---|---|---|---|---|---|---|---|---|
| HGL-1-544-065 | 544 | 0.65 | 330 | 4 X 8mm | 2.8 | 8 | 356 | 12.7 | 76 | 45 |
| HGL-1-544-100 | 544 | 1.00 | 330 | 4 X 8mm | 3.8 | 9 | 312 | 19.3 | 116 | 45 |
| HGL-1-544-125 | 544 | 1.50 | 330 | 4 X 8mm | 5.6 | 14.5 | 307 | 28.9 | 174 | 45 |
