Max. Static Load2500 Kg
BrakeDC 110V, 1.2 A
Brake TypeDisc
Pole20
Volts380 V
RatingIP 41
Weight190 Kg
| Type | Load [In kg] |
Car Speed [In m/sec] |
Sheave [In mm] |
Rope [In mm] [Pitch 12mm] |
Power [ KW ] |
Rated Current [ A ] |
Rated Tourque [ Nm.] |
Frequency [ Hz ] |
Speed [ RPM ] |
Travel Height [ Mtrs ] |
|---|---|---|---|---|---|---|---|---|---|---|
| HGL-600-8P-150 | 544 | 1.50 | 320 | 5 x 8 Ø | 4.8 | 13.0 | 257 | 29.8 | 180 | 60 |
| HGL-600-8P-175 | 544 | 1.75 | 320 | 5 x 8 Ø | 5.5 | 14.5 | 257 | 34.8 | 209 | 60 |
| HGL-600-8P-200 | 544 | 2.00 | 320 | 5 x 8 Ø | 6.5 | 20.0 | 257 | 39.8 | 239 | 60 |
| HGL-600-10P-065 | 680 | 0.65 | 320 | 5 x 8 Ø | 2.7 | 8.0 | 320 | 12.9 | 78 | 60 |
| HGL-600-10P-100 | 680 | 1.00 | 320 | 5 x 8 Ø | 4.0 | 11.0 | 320 | 20.0 | 119 | 60 |
| HGL-600-10P-125 | 680 | 1.25 | 320 | 5 x 8 Ø | 5.0 | 15.0 | 320 | 24.8 | 149 | 60 |
