Max. Static Load3000 Kg
BrakeDC 110V, 2.0 A
Brake TypeDrum
Pole24
Volts380 V
Weight320 Kg
| Type | Load [In kg] |
Car Speed [In m/sec] |
Sheave [In mm] |
Rope [In mm] [Pitch 12mm] |
Power [ KW ] |
Rated Current [ A ] |
Rated Tourque [ Nm.] |
Frequency [ Hz ] |
Speed [ RPM ] |
Travel Height [ Mtrs ] |
|---|---|---|---|---|---|---|---|---|---|---|
| HGL-1-680-065 | 680 | 0.65 | 400 | 4 X 10mm | 3.6 | 9 | 554 | 12.4 | 62 | 80 |
| HGL-1-680-100 | 680 | 1.00 | 400 | 4 X 10mm | 4.6 | 12 | 462 | 19 | 95 | 80 |
| HGL-1-680-150 | 680 | 1.50 | 400 | 4 X 10mm | 7 | 18 | 462 | 28.62 | 143 | 80 |
| HGL-1-680-175 | 680 | 1.75 | 400 | 4 X 10mm | 8.2 | 18 | 462 | 33.39 | 167 | 80 |
