Max. Static Load4500 Kg
BrakeDC 110V, 2.2 A
Brake TypeDisc
Pole20
Volts380 V
RatingIP 41
Weight300 Kg
| Type | Load [In kg] |
Car Speed [In m/sec] |
Sheave [In mm] |
Rope [In mm] [Pitch 12mm] |
Power [ KW ] |
Rated Current [ A ] |
Rated Tourque [ Nm.] |
Frequency [ Hz ] |
Speed [ RPM ] |
Travel Height [ Mtrs ] |
|---|---|---|---|---|---|---|---|---|---|---|
| HGL-900-16P-175 | 1088 | 1.75 | 320 | 8 X 8Ø | 11.0 | 28.0 | 510 | 34.8 | 209 | 80 |
| HGL-900-16P-200 | 1088 | 2.00 | 320 | 8 X 8Ø | 13.0 | 35.0 | 510 | 39.8 | 239 | 80 |
| GL-900-20P-125 | 1360 | 1.25 | 320 | 8 X 8Ø | 10.0 | 27.0 | 640 | 24.8 | 149 | 80 |
| GL-900-20P-150 | 1360 | 1.50 | 320 | 8 X 8Ø | 12.0 | 32.0 | 640 | 29.8 | 180 | 80 |
| GL-900-20P-175 | 1360 | 1.75 | 320 | 8 X 8Ø | 14.0 | 37.0 | 640 | 34.8 | 209 | 80 |
| GL-900-20P-200 | 1360 | 2.00 | 320 | 8 X 8Ø | 16.0 | 42.0 | 640 | 39.8 | 239 | 80 |
| HGL-900-22P-065 | 1500 | 0.65 | 320 | 8 X 8Ø | 6.0 | 17.0 | 720 | 12.9 | 78 | 80 |
| HGL-900-22P-100 | 1500 | 1.00 | 320 | 8 X 8Ø | 9.0 | 24.0 | 720 | 20.0 | 119 | 80 |
| HGL-900-22P-125 | 1500 | 1.25 | 320 | 8 X 8Ø | 11.0 | 28.0 | 720 | 24.8 | 149 | 80 |
| HGL-900-22P-150 | 1500 | 1.50 | 320 | 8 X 8Ø | 13.5 | 36.0 | 720 | 29.8 | 180 | 80 |
| HGL-900-22P-175 | 1500 | 1.75 | 320 | 8 X 8Ø | 15.5 | 40.0 | 720 | 34.8 | 209 | 80 |
| HGL-900-22P-200 | 1500 | 2.00 | 320 | 8 X 8Ø | 18.0 | 48.0 | 720 | 39.8 | 239 | 80 |
