Max. Static Load2300 Kg
BrakeDC 110V, 1.0 A
Brake TypeDisc
Pole20
Volts380 V
RatingIP 41
Weight170 Kg
| Type | Load [In kg] |
Car Speed [In m/sec] |
Sheave [In mm] |
Rope [In mm] [Pitch 12mm] |
Power [ KW ] |
Rated Current [ A ] |
Rated Tourque [ Nm.] |
Frequency [ Hz ] |
Speed [ RPM ] |
Travel Height [ Mtrs ] |
|---|---|---|---|---|---|---|---|---|---|---|
| HGL-500-6P-150 | 408 | 1.5 | 320 | 4 x 8Ø | 3.5 | 9.0 | 190 | 29.8 | 180 | 60 |
| HGL-500-6P-175 | 408 | 1.75 | 320 | 4 x 8Ø | 4.7 | 12.5 | 215 | 34.8 | 209 | 60 |
| HGL-500-6P-200 | 408 | 2.00 | 320 | 4 x 8Ø | 5.4 | 14.5 | 215 | 39.8 | 239 | 60 |
| HGL-500-8P-065 | 544 | 0.65 | 320 | 4 x 8Ø | 2.1 | 7.0 | 257 | 12.9 | 78 | 30 |
| HGL-500-8P-100 | 544 | 1.00 | 320 | 4 x 8Ø | 3.2 | 9.7 | 257 | 20.0 | 119 | 30 |
| HGL-500-8P-125 | 544 | 1.25 | 320 | 4 x 8Ø | 4.0 | 13.0 | 257 | 24.8 | 149 | 30 |
