Max. Static Load6500 Kg
BrakeDC 110V, 1.0 A
Weight 520 Kg
| Model | Load [In kg] |
Speed [In m/sec] |
Ratio | Sheave [In mm] |
Rope [In mm] [PITCH 19M.M.] |
Ropping | Power [ KW ] |
Power [ HP ] |
Pole | Travel / Height [ Mtrs. ] |
|---|---|---|---|---|---|---|---|---|---|---|
| HE - 7 | 680 | 1.00 | 80/2 | 530 | 4X13 | 1:1 | 9 | 12 | 4P | 80 |
| HE - 7 | 680 | 1.50 | 53/2 | 530 | 4X13 | 1:1 | 11 | 15 | 4P | 80 |
| HE - 7 | 884 | 0.65 | 80/2 | 530 | 4X13 | 1:1 | 9 | 12 | 6P | 60 |
| HE - 7 | 884 | 1.00 | 80/2 | 530 | 4X13 | 1:1 | 9 | 12 | 4P | 50 |
| HE - 7 | 1020 | 0.65 | 80/2 | 530 | 4X13 | 1:1 | 11 | 15 | 6P | 30 |
| HE - 7 | 1020 | 1.00 | 80/2 | 530 | 4X13 | 1:1 | 13 | 17.5 | 4P | 30 |
| HE - 7 | 1020 | 1.00 | 53/2 | 710 | 4X13 | 2:1 | 7.5 | 10 | 4P | 40 |
| HE - 7 | 1300 | 1.00 | 53/2 | 710 | 4X13 | 2:1 | 9 | 12 | 4P | 40 |
| HE - 7 | 1500 | 0.50 | 80/2 | 530 | 4X13 | 2:1 | 9 | 12 | 4P | 50 |
| HE - 7 | 1500 | 0.75 | 53/2 | 530 | 4X13 | 2:1 | 9 | 12 | 4P | 50 |
| HE - 7 | 2000 | 0.32 | 80/2 | 530 | 4X13 | 2:1 | 9 | 12 | 6P | 30 |
| HE - 7 | 2000 | 0.50 | 80/2 | 530 | 4X13 | 2:1 | 11 | 15 | 4P | 26 |
